Application:
Widely used in the installation of high-demand clean rooms, large-area vertical laminar flow, 100-level laminar flow hood and HEPA high-efficiency filter.
The liquid tank sealing high efficiency non-separator air filter product has light weight, small volume and reliable sealing because it has no partition plate.Features:
good sealing performance, easy installation, high efficiency, low resistance and low operating cost.
Frame material:aluminum profile
Sealant: Polyurethane AdhesiveSealing medium: liquid tank seal
Technical Parameter
| Model | Dimensions（mm） |
Rated air volume（m³/h） |
Initial resistance（Pa） |
Filtration efficiency（%） |
Dust holding capacity（g） |
|
| GK-5A | 320*320*220 | 500 | Straight partition structure≤235.44Pa |
＜99.99Sodium flame method |
400 | |
| GK-7A | 484*484*150 | 700 | 450 | |||
| GK-8A | 600*600*150 | 800 | 500 | |||
| GK-10A | 484*484*220 | 1000 | 500 | |||
| GK-10C | 610*610*150 | 1000 | 600 | |||
| GK-12A | 820*600*150 | 1200 | 750 | |||
| GK-15A | 630*630*220 | 1500 | 900 | |||
| GK-15B | 726*484*220 | 1500 | 750 | |||
| GK-15C | 915*610*150 | 1500 | 850 | |||
| GK-20A | 968*484*220 | 2000 | 1200 | |||
| GK-20B | 1220*610*150 | 2200 | 1200 | |||
| GK-22A | 945*630*220 | 2200 | 1400 | |||
| GK-20B | 1260*630*220 | 3000 | 1600 |
